  Our new Somfy shade driver has been re-written to take advantage of the new features available within the latest releases of Control4.  It has been written from the ground up in order to give you a seamless experience. Our location tracking is the most precise experience you will find and is just like having a two-way shade installed. The true benefit of our driver is within our unique shade tracking which offers an experience unlike any other.



Somfy is one of the most popular blind motor systems.  This driver was designed to give customers and installers more tools and features integrating Somfy into Control4. This driver was re-designed to take advantage of the new V2 proxy which is available in Control4.

FEATURES:

  • Move blinds up/down/stop from any Control4 interface
  • Easy to integrate blind 'toggle' setting.  Press toggle, blind goes up, press it again, blind stops, press again blind goes down.
  • Current level selection and notification in Control4 (Note: 0 = Fully Closed, 100 = Fully Open)
  • Events for moving, stopped, level, etc.
  • Easy Control4 keypad integration using Composer 'CONNECTIONS' menu
  • Control4 Keypad LED state changes when blinds are closed/open
  • Allows blinds to be placed into different rooms.
  • Gives dealer more installation flexibility and a better user experience than generic Control4 driver

 REQUIREMENTS:

  • Somfy URTSII Module (RS232)
  • Somfy 1810791 RTS Repeater (for better signal communication)

Driver is provided by Cinegration LLC.  All rights reserved.



No posts found

Somfy is one of the most popular shade motor systems.  This driver was designed to give customers and installers more tools and features integrating Somfy into Control4.



Features:

  • Precision shade tracking
  • Move blinds up/down/stop from any Control4 interface
  • Easy to integrate blind 'toggle' setting.  Press toggle, blind goes up, press it again, blind stops, press again blind goes down.
  • Current level selection and notification in Control4 (Note: 0 = Fully Closed, 100 = Fully Open)
  • Events for “Is moving up” and “Is moving down”
  • Easy Control4 keypad integration using Composer 'CONNECTIONS' menu
  • Control4 Keypad LED state changes when blinds are closed/open
  • Supports both RS485 and RS232 versions



Setup:

  • 1. Install and enroll your shades, please refer to somfy documentation on how to do this properly. Set the correct limits of your shades before adding them to Control4.
  • 2. Add the Somfy Main driver to your project and add your activation key. You must add in the main driver first. If you fail to do so, the separate shade drivers will not auto-bind correctly.
  • 3. Add in your individual blind drivers for each room, these drivers will automatically bind with the main Somfy driver.
  • 4. For each shade that you add, you must select the “blind type” and “blind movement” at the top of the property’s page. If you fail to do this you will not get the appropriate animation within navigator.
  • 5a.If your shade is a louver type device read this step, if not proceed to step 6.  You may notice your louver type shade when fully opened does a complete rotation. To fix this and make it easy we will need to dial in the time it takes to reach the angle at which you want you shade to be opened. So, fully closed would be perpendicular to the ground. While fully opened would be parallel to the ground.
  • 5b. Time the amount of time it takes to reach your ideal “parallel” to the ground state. Now enter that time in the open and close time for that specific shade.
  • 5c. Now we will navigate to the driver actions tab. Select the “Enable Send Stop Louver Type” selection, and press the set button to the right. If you want to flip the direction that your shade is opened/closed you will then select the “Shade Direction Reversed” driver action.
  • 6. Choose your shade address and unit address of your Somfy URTS module.
  • 7. We will now time how long it takes the blind to travel up/down. This gives
  • 8. Using navigator or within composer complete a full movement to open and close the shade. Keeping track of the time it takes for both movements.
  • 9. Enter the time it takes to open the blind in the “Open Time” property field. Followed by the time it takes to close in the “Close Time” field.
  • 10. Your shades are now calibrated. Enjoy.



This driver contains code written by Cinegration.  Any modification to this driver or any driver written by Cinegration without the express consent will void all warranties, constitute a ban on all drivers released by Cinegration and potentially legal action.





Troubleshooting:

                Symptom: Shades are not being controlled.

                                Step One: Check the wiring…





IF WIRING TO A HC200 or HC250 Controller:

                Here is the pin out configuration for these controllers.  Terminate a CAT5e cable 568A.  Splice the wiring to a stereo 1/8” mini cable where:

Brown pair connects to the bottom pin of the mini cable

Solid Orange connects to the middle pin of the mini cable

White/Orange connects to the top pin of the mini cable



If using Somfy RS485 -> RS232 adapter: These will only work with a HC800, HC300, I/O Extender as their device is port powered.



Warranty:

         Cinegration strives to provide fully working drivers without defects.  However, changes and bugs may be found.  Because of this, any bug/maintenance update to this driver will be free of charge.  However, due to the ever changing nature of computer and audio/video systems, if a new version of the Control4® software creates issues with this driver, or feature enhancements, an upgrade version will be provided for an additional expense or free as determined by Cinegration LLC.



Thank you for choosing a driver by: Cinegration LLC.

  • 1006 - Fixed issue where programming actions would not send the correct direction.
  • 1005 - Fixed issue where shade would jump to opposite direction.
  • 1004 - Fixed shade toggle logic.
  • 1003 - Fixed Driver not persisting current state.
  • 1002 - Fixed license validation so old somfy driver licenses will work
  • 1001 - Moved to DriverCentral.
