Niles ZR-6

Control a Niles ZR-6 System with up to 18 zones of audio via a Control4 system
MSRP: $149.00
[Sign in for more info]
Cinegration LLC
Please sign in to buy

This product cannot be added to the
cart because you are not logged in.

Many existing homes had Niles ZR-6 whole house audio systems installed in them.  This driver allows a dealer to integrate up to 18 zones of audio via 1 RS232 port on any Control4 system.

FEATURES:

  • 2 Way Volume Feedback (Note: Set volume is not allowed as Niles doesn't support it)
  • 2 Way Mute and Power Feedback
  • Polling of Active Zones so dealers can keep customer's existing Niles keypads for audio support
  • Direct Tuner Control for Both AM and FM

REQUIREMENTS:

  • Niles ZR-6 (RS232)
  • This driver will NOT WORK on the ZR-4630

Driver is provided by Cinegration LLC.  All rights reserved.

No posts found

Write a review

Note: THIS DRIVER DOES NOT CONTROL THE NILES ZR-4630. The ZR-4630 is an IR only system.

Note: There is a switch on the front of the Niles ZR6 to allow the front RS232 jack to be used for uploading a project.  Make sure this connection is set to 'NORMAL'

Note: Control4 RS232 DB9-> 1/8" Mini cables need to have pins 2/3 reversed for proper RS232 setup.

Purpose of Driver:
Many existing homes had sound systems that have Niles ZR-6 equipment in them. This driver allows a dealer to integrate up to 18 zones of audio via 1 RS232 port on any control4 system.

Driver Features:
ñ Niles ZR-6 Feature
◦ 2 Way Volume Feedback (note: set volume is not allowed as Niles doesn't support it)
◦ 2 Way Mute and Power Feedback
◦ Polling of Active Zones so dealers can keep customers existing niles keypads for audio support
◦ Direct Tuner Control for Both AM and FM


Installation Procedure:
Dealers need to install the Niles ZR-6 first and verify functionality before implenenting this driver.
ñ Niles Setup
◦ Connect a DB-9 to 1/8” Stereo Plug from any Control4 RS232 port to the RS232 jack on the Niles piece.
◦ Record Zones and Sources on the equipment
ñ Control4 Setup
◦ Add Niles driver (under Receivers, Manufacture Niles) to the system and 'bind' the zones and sources to their corresponding equipment
◦ Under the properties menu, choose how many zones of audio the ZR-6 is using (this property determines which zones the Control4 will poll)
◦ Connect the serial port to the driver
ñ Once this is done the driver should be ready for deployment.
◦ You will know the driver is communicating with the ZR-6 when the Driver Information tab displays “Niles Communction Good” with a firmware of the unit
ñ Notes on the AM/FM Radio
◦ The tuner is a toggling input between AM and FM. Pressing AM or FM via a Control4 screen will toggle between inputs. You can also press the 'SELECT' button on a Control4 SR250 remote to do this also
◦ Direct Tuning support is available and is available via pressing number buttons on either a Control4 screen or a SR250
▪ If you are on AM you must enter a 4 digit number for the command to work (e.g. 0850 for 850AM)
▪ If you are on FM you only need to enter the numbers for the station (e.g. 973 for 97.3FM or 1067 for 106.7FM)
◦ This driver does support Station media via the Media Tab in Composer.
▪ To use this, click on the AM or FM cloud in Medai and press New
▪ Enter at least the name and the Station (station format will be as follows, XXXXAM for am and XXX.XFM for FM where X is a number)
▪ Click OK


Notes:
ñ This driver does not control any iPod connected to the ZR-6 directly. It can however, choose that input and control volume etc...
ñ This driver contains code written by Cinegration. Any modification to this driver or any driver written by Cinegration without the express consent will void all warranties, constitute a ban on all drivers released by Cinegration and potentially legal action.
ñ This driver has been designed to work with Control4® 2.6.0 System



Warranty:
Cinegration strives to provide fully working drivers without defects. However, changes and bugs may be found. Because of this, any bug/maintenance update to this driver will be free of charge. However, due to the ever changing nature of computer and audio/video systems, if a new version of the Control4® software creates issues with this driver, or feature enhancements, an upgrade version will be provided for an additional expense or free as determined by Cinegration LLC.

Thank you for choosing a driver By: Cinegration LLC.

  • 1001
    • migration to driverCentral







OLD UPDATES

Updates

◦  Version 8.0.0

▪  Conversion to HouseLogix

◦  Version 8.0.1

  • In-House Update

◦  Version 8.0.3

  • Added support for Cinegration Showroom License
